Description Type
Adjustable front axle track - tire 14.9-24 1400 mm 1519 mm 1580 mm 1699 mm
1600 mm 1719 mm 1780 mm 1899 mm
Adjustable steering angle 40°
Axle oscillation 13.5°
Camber 1°
Kingpin inclination 8°
Caster 5°
Toe-in 0-3
Distance between flanges 1640 mm
Hub diameter 220.6 mm
Diameter of the circumference of the front wheel
nuts
275 mm
Adjustment screw M18 x 1.5 (8+8)
Turn radius without brake with the traction o 4560 mm
Turn radius without brake with the traction on 4850 mm
1.1.2.11 Hydraulic lift
Description Type
Controls
Automatic depth control with variable sensitivity (changing the three-point
and undulation connection points)
For position, depth, traction, reaction and lowering speed
Remote control valve for
external circuit
Up to 3 dual action valves with quick coupling + J1036 controlled outlet
1.1.2.12 Mechanically controlled hydraulic lift
Description Type
Valves ISO A quick coupling
Quantity Maximum 3 valves
Model Single or dual action + Controlled Outlet
Circuit model Series with the hydraulic system
Relief valve pressure 180 bar
1.1.2.13 Maximum lift strength
Description Type
Hitch system Category II (NBR 8566)
Maximum lifting capacity (eye ring) 3860 kgf
610 mm of the eye ring 3710 kgf
GUID-F9CCADAB-094D-454A-AFB4-746CA0143D2C [V2]
GUID-4884FBFB-5690-4B39-B8F6-837D80239410 [V2]
GUID-3760835A-5552-4F1D-B526-9BA37DF6D3D3 [V3]
1. Introduction
1-11
ACX2831410
