13
7.2 TIRE INFLATION OR PRODUCTS WITH A VALVE STEM
1. Place connector (chuck) on valve stem.
2. Push connector toward valve stem and close thumb latch.
3. Make sure connector is pushed onto valve stem as far as possible before
closing thumb latch.
4. Press unit’s ON/OFF button (11) to activate the unit’s display.
5. Press INFLATOR pushbutton (7) to activate the compressor.
6. Press unit’s UP (17) or DN (18) to select desired psi.
7. Press INFLATOR pushbutton again to begin inflation.
8. When desired pressure is reached, press INFLATOR pushbutton once more
to stop inflation process.
9. Open thumb latch and remove connector from valve stem and store.
IMPORTANT:
Always leave the thumb latch in the open position when storing unit.
7.3 INFLATING OTHER ARTICLES (WITHOUT VALVE STEM)
Inflation of other items requires use of one of the adapters (nozzles).
1. Open the hatch and remove the nozzles noting their storage positions.
2. Insert appropriate adapter (e.g. needle) into connector (chuck) and close
thumb latch.
3. Refer to Table III, Typical Inflation Times, for approximate filling pressure
and time. Small items such as volleyballs, footballs, etc. inflate very
rapidly.
4. Insert adapter (e.g. needle) into item to inflate to appropriate pressure.
5. Press unit’s ON/OFF button (11) to activate the unit’s display.
5. Press INFLATOR pushbutton (7) to activate the compressor.
6. Press unit’s UP (17) or DN (18) to select desired psi.
7. Press INFLATOR pushbutton again to begin inflation.
8. When desired pressure is reached, press INFLATOR pushbutton once more
to stop inflation process.
7. Remove adapter from inflated item and store.
7.4 TYPICAL INFLATION TIMES
The following are approximate pressure and inflation times for various items.
WARNING:
Always follow tire manufacturers recommendations for pressure on item to be
inflated.
