15
THREE-THREAD OVERLOCK WITH ONE NEEDLE
By threading the LEFT needle only a width of 6 mm will be produced and by threading the
RIGHT needle only a width of 3.8 mm will be produced.
CONVERTING TO TWO-THREAD USE
To convert to two thread use, first open the front cover and working table and raise needle to its highest
point by turning hand wheel towards you. Remove the right needle and use the left needle.
Please keep the unused needle on the needle pad.
Pull out the convertor as shown in Fig.1.
Attach the two-thread convertor onto the upper looper as shown in Fig. 2, Fig.3.
When not using convertor, insert it deep and keep as illustrated in Fig.4.
Fig.1
1
2
Fig. 4
Fig. 3
Fig. 2
2
Two-thread
overlock
convertor
Upper
looser
1
To Next Page
