Installation
1. Thishoodneedtobesupportedfromasolidstructuralbox
madeof2x4or2x6.(Fig6)
2. Thewoodframeneedstobeabovethedrywallceiling,themetalframe-below.
3. Youneedtoattachthehoodframetothewoodenboxaboveitusingwoodscrewsinthe4corners.
SAFETY WARNING: Risk of electrical shock. this range hood must be properly grounded. Make sure this is done
by qualied electrician in accordance with all applicable national and local electrical codes. Before connecting wires,
switch power off at service panel and lock service panel to prevent power from being switched on accidentally.
4. Connecttherangehoodtoadesignatedstandardoutletorcutofftheplugandconnectthreewires(black,whiteand
green)tohousewiresandcapwithwireconnectors.Connectaccordingtocolors(i.e.blacktoblack,whitetowhite,and
greentogreen)asshowninFigure8.
8” min
Figure 6
wood trusses
backing
Adjustablemetalframe
bolted to the main frame
Main frame attached
tothestructuralbox
belowthedrywall
with 4 wood screws
3-1/2”woodscrews
Main hood support
brackets
