27
EN
13F4, 13A4, 13A4.B - 13F7, 13A7, 13A7.B
Parameter configuration
Changes are made connecting one electronic unit at a time.
In systems with several electronic units, one unit must be
identified as a MASTER and the other units as SLAVE units,
regardless of model or type (alphanumeric, buttons, landing).
All entrance panels are supplied with the electronic unit set as
MASTER (ID = 1).
Procedure for accessing parameter configuration
mode
You have to start with the electronic unit in a state of rest: there
must be no calls in progress, no self-starting or anything similar.
Press buttons
R
+
4
GHI
. Release the buttons.
Key in the password, by default
6
MNO
5
JKL
4
GHI
3
DEF
2
ABC
1
. Every time a button is pressed there will be a short “beep”, an
asterisk “*” appears on the display, and there are a further 25 s
in which to press the next button. If you let the timeout elapse,
the electronic unit will return to rest.
After entering the password, press the
button. If the pass-
word is correct, the electronic unit goes into parameter configu-
ration mode. If the password is wrong, the electronic unit exits
the procedure and reverts to at-rest status. The operation must
be repeated.
Note: The information that appears in square brackets refers to
the case of active Horizontal Installation, paragraph 1.2.
Parameter default settings
Table 2
Parameter Default
1.0 Message language Italian
1.1 Entrance panel ID 1
1.2 Installation Vertical Bus
1.3 Initial ID (+) 1
1.4 Final ID (+) 1000
1.4A
IU per router (+)
200
1.5 First button ID 1
1.6 Button remapping HW
1.7 Single buttons Yes
1.8 No. coding digits Sequential coding
1.9 Lock code R+1
2.0 Preferential code Not assigned
2.1 Preferential code Not assigned
2.2 Lock codes Not assigned
2.3 F1 codes Not assigned
2.4 F2 codes Not assigned
2.5 No. Dev. (-) Not assigned
Parameter Default
2.6 Search all contacts No
2.7 Contacts Name Not assigned
2.8 Program Password 654321
2.9 Answer time 30 s
3.0 Conversation time 120s
3.1 Self-start time 10 s
3.2 Lock time 1 s
3.3 Function 1 Time 1 s
3.4 Function 2 Time 1 s
3.5 Door Open send time 1 Min.
3.6 External volume 3
3.7 Internal volume 3
3.8 Balancing 8
3.9 Chime Volume 0
3.10 Lock interlock No
3.11 Enabling Direct enabled, Com
-
mon disabled
4.0 Entrance panel chime Yes
4.1 No. chime cycles 2
4.2 Switchboard pb Not assigned
4.3 Button Audio call Not assigned
4.4 Com. lock Not assigned
4.5 F1 common Not assigned
4.6 F2 common Not assigned
4.7 Disable SB search (*) Yes
4.8 Disable self-start (*) No
4.9 Seq. Self-start (*) Not assigned
4.10 Date and Time format 01/01/2014 00:00
5.0 Clock 01/01/13 00:00
5.1 Enable timed codes No
5.2 First Time Call 0
5.3 Last Time Call 0
5.4 Band Not assigned
5.5 Device (°)
5.6 Button (°)
Notes: (*) configurable only with MASTER or horizontal
electronic unit, (°) only in the vertical configuration, (+) only
in the horizontal configuration, (-) only if No. Coding Digits
is not Sequential.
