3.6) Reference technical norms
The stairlift complies with the following norms:
98/37 EEC
98/79 EEC
Machinery Directive and subsequent amendments
EN 292-1 Safety of machinery
Fundamental concepts, general design principles.
Technology, basic methodology.
EN 292-2 Safety of machinery
Fundamental concepts, general design principles.
Specifications and technical principles.
EN 418 Safety of machinery
Emergency stop device.
Functional aspects - Design principles
EN 60204-1 Safety of machinery
Electrical equipment of machinery
Part. 1: General rules
EN 50081-1 Electromagnetic compatibility
General standard on emission.
Residential, commercial and light industrial
environments.
EN 50082-1 Electromagnetic compatibility
General standard on immunity.
Residential,commercial and light industrial
environments.
4) TECHNICAL SPECIFICATIONS
- Drive system
Irreversible worm gear Ratio 1/80
- Performance levels
Travel direction Forward/back
Speed (up/down) 0.07 m/s
Capacity 1 person
Gradient from 0° to 50°
Load capacity V64/74
230 kg up to 45°
200 kg up to 50°
- Duty cycles
Normal service 20 min/hour max.
- Ambient conditions
Temperature From -10°C to +60°C
Humidity maximum 70%
(use in bathrooms and swimming-pools is not permitted)
- Electric system
Drive motor 220 VAC single-phase 50 Hz - 0.75 kW
Absorption 8 A
Circuit-breaker
- Controls
Up/down/stop button Timed (starting delay 3 seconds)
Emergency stop button with detent (immediate stop)
Key-switch
Circuit-breaker reset button
(to be provided by the customer).
