Viotek GNV27DB User Manual

6
Section 3: Product Overview
3.1 – Monitor Buttons
7
Audio Output: Insert one end of the audio cable into an external audio
source, e.g., speakers or headphones, to pass audio signals through the
monitor.
8
DP Connector: Insert one end of the DP cable into the computer’s DP output
and connect the other end to the monitor’s DP port.
9
HDMI Connectors: Insert one end of the HDMI cable into the computer’s
HDMI output and connect the other end to the monitor’s HDMI port.
10
Power Connector: Insert the power cable to supply power to the monitor.
7 8 9 10
2 3 4 5 6 1
1
M Menu Button
: Press to display the OSD menu or enter sub-menus.
2
Down Button
: Press to move down in the menus.
3
Up Button
: Press to move up in the menus.
4
E Exit Button
: Press to exit.
5
Power Button
: Press to turn the monitor on/off.
6
LED Indicator: Changes colors to indicate status. Refer to Section 7.
3.2 – Monitor Ports
HDMI 2.0 HDMI 1.4
GNV27DB.indd 6 2020/3/26 18:39:13

Viotek GNV27DB Specifications

General

Model Number	GNV27DB
LED Indicator	Power on: Blue (solid); Power saving: Blue (flashing)
Screen Size	27’’
Curvature	1500R
Viewing Angle	178°(H) / 178°(V)
Aspect Ratio	16:9
Resolution	2560 x 1440p
Backlight	E-LED
Typical Brightness	250 cd/m2
Default Color Temp.	6500
Color Gamut	96% sRGB; 85% NTSC; DCI-P3 90%; Adobe RGB 83%
Contrast Ratio	3000:1 (Static)
Dot Pitch	0.2331 x 0.2331 mm
Refresh Rate	144Hz
Response Time	6ms (GTG)
Ports	HDMI 2.0 x 1, HDMI 1.4 x 2, DP x 1, Audio out x 1
Power	DC 12V, Min 4A
Power Consumption	Typical: 37W, Max: 58W; Standby <=0.5W
OSD Language	English, Español, Русский, Français, 한국, 日本語, 简体 中文
Usage Temp.	32°F~95°F (operating), -4°F~140°F (storage), 10-90% RH (non-condensing)

Weight and Dimensions

Tilt Angle	Forward 5°+ 2°; Backward 15°+ 2°
VESA Mounting	75 x 75 mm
Dimension (With Stand)	24.26 x 17.84 x 7.7 in (616.2 x 453.1 x 195.7mm)
Weight	10.69 Ib. / 14.82 Ib. (incl. packaging)
