Viotek GNV27DB User Manual

8
Section 5: Mount Installation
1. Open the package and take out the product with foam still attached. Gently
place it on a desktop or table. Remove the extra parts and the foam covering the
monitor. If the monitor is already attached to the stand, remove the stand.
Button
2. Press the button to remove the adapter on back of monitor, then tighten the
included four NO. 2 screws onto the mounting holes on back of monitor.
NO. 2
Screws x 4
3. Install the monitor on the wall, mount, or xture as desired.
Mount
(not included)
GNV27DB.indd 8 2020/3/26 18:39:15

Viotek GNV27DB Specifications

General

Model Number	GNV27DB
LED Indicator	Power on: Blue (solid); Power saving: Blue (flashing)
Screen Size	27’’
Curvature	1500R
Viewing Angle	178°(H) / 178°(V)
Aspect Ratio	16:9
Resolution	2560 x 1440p
Backlight	E-LED
Typical Brightness	250 cd/m2
Default Color Temp.	6500
Color Gamut	96% sRGB; 85% NTSC; DCI-P3 90%; Adobe RGB 83%
Contrast Ratio	3000:1 (Static)
Dot Pitch	0.2331 x 0.2331 mm
Refresh Rate	144Hz
Response Time	6ms (GTG)
Ports	HDMI 2.0 x 1, HDMI 1.4 x 2, DP x 1, Audio out x 1
Power	DC 12V, Min 4A
Power Consumption	Typical: 37W, Max: 58W; Standby <=0.5W
OSD Language	English, Español, Русский, Français, 한국, 日本語, 简体 中文
Usage Temp.	32°F~95°F (operating), -4°F~140°F (storage), 10-90% RH (non-condensing)

Weight and Dimensions

Tilt Angle	Forward 5°+ 2°; Backward 15°+ 2°
VESA Mounting	75 x 75 mm
Dimension (With Stand)	24.26 x 17.84 x 7.7 in (616.2 x 453.1 x 195.7mm)
Weight	10.69 Ib. / 14.82 Ib. (incl. packaging)
