Viotek GNV27DB User Manual

7
Section 4: Stand Installation
Keep the foam underneath the monitor before attaching the stand.
1. Open the package and take out the monitor with foam still attached. Gently place
it top-down on a desktop or table.
2. Take out the stem and base. Use the included screwdriver and one screw to
fasten base to the stem.
Screw x 1
Stand Stem
Base
3. Remove the foam covering the bottom of the monitor, then remove the adapter
from the back of monitor. Use two NO. 1 screws to fasten adapter onto the stem.
Adapter
Screws x 2
4. With the stand fully assembled, reattach it onto the back of monitor. Then remove
the remaining foam on monitor and stand it up on a at, level desktop or table.
Press the button to remove the monitor from the bracket if mounting.
Button
Make sure the monitor is laid on a at surface before removing the stand.
GNV27DB.indd 7 2020/3/26 18:39:14

Viotek GNV27DB Specifications

General

Model Number	GNV27DB
LED Indicator	Power on: Blue (solid); Power saving: Blue (flashing)
Screen Size	27’’
Curvature	1500R
Viewing Angle	178°(H) / 178°(V)
Aspect Ratio	16:9
Resolution	2560 x 1440p
Backlight	E-LED
Typical Brightness	250 cd/m2
Default Color Temp.	6500
Color Gamut	96% sRGB; 85% NTSC; DCI-P3 90%; Adobe RGB 83%
Contrast Ratio	3000:1 (Static)
Dot Pitch	0.2331 x 0.2331 mm
Refresh Rate	144Hz
Response Time	6ms (GTG)
Ports	HDMI 2.0 x 1, HDMI 1.4 x 2, DP x 1, Audio out x 1
Power	DC 12V, Min 4A
Power Consumption	Typical: 37W, Max: 58W; Standby <=0.5W
OSD Language	English, Español, Русский, Français, 한국, 日本語, 简体 中文
Usage Temp.	32°F~95°F (operating), -4°F~140°F (storage), 10-90% RH (non-condensing)

Weight and Dimensions

Tilt Angle	Forward 5°+ 2°; Backward 15°+ 2°
VESA Mounting	75 x 75 mm
Dimension (With Stand)	24.26 x 17.84 x 7.7 in (616.2 x 453.1 x 195.7mm)
Weight	10.69 Ib. / 14.82 Ib. (incl. packaging)
