Vision SB-1900P User Manual

7
Identifying the Parts
Main Unit
1211 139 10
1 2 3 4 5
6 7
8
1
3
4
5
2
6
7
1 button
Turn ON or turn OFF the unit.
2 SOURCE button
Select the play function.
3 EQ button
Select equalizer (EQ) effect.
4
BF
/PAIR button
Play/pause/resume playback in Bluetooth mode.
Press and hold to activate the pairing
function in Bluetooth mode or disconnect
the existing paired Bluetooth device.
5
VOL+/VOL- buttons
Increase/decrease the volume level.
6 LED Indicators
• Red : STANDBY mode
• Green : AUX mode
• Blue : Bluetooth mode
White : HDMI 1 mode
White flash : HDMI 2 mode
• Orange : HDMI ARCmode
7 Remote Control Sensor
8 Wall bracket screws
9 DC Socket
10 USB Socket
The USB socket is for service only.
11 HDMI IN [
1
,
2
] Sockets
12 HDMI OUT (ARC) Socket
13 AUX Socket
Remote Control
1 ON Turn ON the unit.
2 OFF Turn OFF the unit.
3 Function buttons Select the play function.
4
VOL+/VOL- Increase/decrease the volume level.
I

/

I Skip to previous/next track in BT mode.
BF
Play/pause/resume playback in BT mode.
5
PAIR Activate the pairing function in Bluetooth
mode or disconnect the existing paired
Bluetooth device.
6 MUTE Mute or resume the sound.
7
FLAT/MOVIE/MUSIC
Select equalizer (EQ) effect.
