• The reservoir or receiver is damaged (e.g. in an accident).
Caution
♦ Handling refrigerant ⇒ Volkswagen ServiceNet; Service
handbook; Environmental protection; Waste disposal;
Current situation; Disposal channels; Disposal of used
oils; Refrigerant oils .
11.1 In the event of leaking or damaged com‐
ponents (apart from the air conditioner
compressor, receiver or reservoir)
11.1.1 If the refrigerant circuit was completely
empty
– Remove defective part.
– Remove air conditioner compressor.
– Remove oil drain screw from air conditioner compressor.
Note
♦
To speed up the draining of the refrigerant oil, rotate the shaft
of the air conditioner compressor by hand using the poly V-
belt pulley or the magnetic clutch.
♦
Pour old refrigerant oil out of air conditioner compressor, han‐
dling refrigerant oil ⇒ Volkswagen ServiceNet; Service hand‐
book; Environmental protection; Waste disposal; Current
situation; Disposal channels; Disposal of used oils; Refrigerant
oils .
♦
Then fill the air conditioner compressor with the quantity of
new refrigerant oil corresponding to the quantity in a genuine
air conditioner compressor ⇒ Rep. gr. 87 .
♦
Different types and quantities of refrigerant oils are required
for different air conditioner compressors ⇒ Rep. gr. 87 .
♦
To ensure proper lubrication of the air conditioner compressor
when it runs for the first time, the air conditioner compressor
must be filled with at least 80 cm
3
of refrigerant oil; the re‐
mainder can be poured into the new reservoir or receiver ⇒
Rep. gr. 87 .
♦
If dirt enters the air conditioner compressor whilst the refrig‐
erant circuit is open (e.g. after an accident), the air conditioner
compressor should be renewed.
♦
Blow through refrigerant circuit with compressed air and re‐
move moisture with nitrogen ⇒ page 65 .
– Renew receiver or reservoir and restrictor.
– Assemble the refrigerant circuit, evacuate it and charge it.
11.1.2 If there is still refrigerant in the refriger‐
ant circuit
– Drain refrigerant circuit.
Amarok 2011 ➤ , Beetle 2012 ➤ , Bora 1999 ➤ , CC 2010 ➤ , CC 2012 ➤ , ...
Air conditioning system with refrigerant R134a - Edition 10.2014
160 Rep. gr.00 - Technical data
