Optional instruments
These instruments are sold as engine accessories by
Volvo Penta.
1 Voltmeter, battery charging
The meter shows the alternator charge current.
During operations the charge voltage must be
around 14 V. When the engine is stopped and
electrical power switched on, battery voltage is
around 12 V.
2 Coolant temperature gauge
The instrument shows engine coolant temperature.
During operations coolant temperature must
normally be between 75-95°C (167-203°F).
3 Fuel level gauge
The fuel level gauge shows the quantity of
remaining fuel.
4 Alarm monitor
The alarm monitor gives a visual warning to call
attention to any alarms that occur.
Instruments and Controls
24 47711262 01-2019 © AB VOLVO PENTA
