Replacing Battery
IMPORTANT:
Make sure that the new battery fulfills the specifications
in Technical Data. Read the information supplied with
the battery before you begin the installation.
IMPORTANT:
Do not disconnect the batteries with the engine
running.
Sensitive electrical components can be immediately
damaged.
WARNING!
Never confuse the positive and negative poles on the
batteries. Risk of arcing and explosion.
Disconnecting (A)
1 Untighten the nut and remove the – cable (black).
2 Untighten the nut and remove the + cable (red).
Remove the battery.
Connecting (B)
Place the new battery.
1 Connect the + cable (red) to the + pole on the
battery and tighten the nut.
2 Connect the – cable (black) to the – pole on the
battery and tighten the nut.
NOTICE! Hand in the old battery to a re-cycling station.
Maintenance
47711262 01-2019 © AB VOLVO PENTA 67
