Group 30: Electrical system Index
153
MID 128 (engine control unit EMS):
SPN Flashcode PID PPID SID PSID FMI Please refer
Electrical fault/ to page:
value fault
Ambient air pressure 108 -/- 108 2, 3, 4 64
Battery voltage 158 -/3.9 (EMS) 158 1 76
-/6.9 (CIU)
Boost pressure 106 3.4/3.5 106 0, 3, 5 58
Boost temperature 105 3.2/6.2 105 0, 4, 5 52
Communication fault J 1939 639 6.5/- (EMS) 231 2 126
6.4/- (CIU)
Controller error 629 9.9/- (EMS) 254 3, 8, 12 132
9.8/- (CIU)
Coolant temperature 110 3.3/6.1 110 1, 3, 4 66
Coolant level 111 2.3/2.2 111 1 72
ECU temperature 8.4/- 55 0, 4, 5 93
Engine speed 190 -/2.6 190 0 84
Engine starter relay 677/1675 4.6 39 3, 4, 5 115
Engine stop switch 520195 4.8/- (EMS) 6 3, 4, 5 87
970 5.3/- (CIU)
Engine sync acknowledge 608 - 98 9 95
Injection control pressure regulator 679 8.3/- 42 3, 4, 5, 6, 13 118
Injector common rail #1–6 651-656 7.1-7.6/- 1–6 3, 4, 5, 7, 12 100
Internal EGR status 8.5/- 19 3, 4, 5, 7 89
Inlet air heater status 626 5.4/- 45 3, 4, 5 33
J 1939 communication bus 639/1675 - 201 9 141
Fuel pressure 94 3.6/3.8 94 1, 3, 5, 7 36
Oil pressure 100 3.1/6.6 100 1, 3, 5 46
Preheat sensor 729 70 3, 4, 5 122
Program memory 639 9.9/- 240 2, 7, 11, 14 131
Rail pressure 164 8.3 164 0, 2, 4, 5 78
Rail pressure release valve 679 8.3 97 0, 7, 11, 14 137
Rail pressure system 1239 96 0, 1, 4, 7, 12 133
Speed sensor, camshaft 636 2.5/- 21 2, 3, 8 105
