8 Operation and use
100_0202_op_0011.fm 33
Start engine
1. Directly aim remote control towards a receiver unit.
2. Briefly press start button of the remote control – the motor will start automatically. When the receiving
units flash yellow, the machine is ready for operation.
8.3.4 Machine with Compatec system (optional)
1. During the first few seconds after starting the machine, a light progress bar appears on the Compatec
display unit.
2. LEDs light up starting from left to right.
3. All LEDs will briefly light up again at reduced brightness.
4. The sensor is thus successfully tested and the Compatec system is ready for operation.
8.4 Operation
In accordance with the intended purpose, the operator should stand behind the machine.
Guide and steer machine using the control handle.
Control machine with remote control.
Item Designation
1 Engine start button
NOTICE
The starting process can take up to 2 minutes. As long as the receiving units light red, the
automatic startup will run. Depending on the operating temperature of the engine, the glow
plugs are optionally preheated and warmed up.
Item Designation Item Designation
1 Compatec - display unit 2 LEDs/light progress bar
NOTICE
If all LEDs light up, the Compatec display unit is fault-free. The LEDs will then switch off
one after the other.
NOTICE
If the brief lighting up of all LEDs does not occur, the sensor has not been successfully
tested. See Troubleshooting chapter.
