BA EZ17 en* 1.1 * ez17t900.fm 9-1
Technical data 9
9 Technical data
9.1 Models and trade names
– see chapter “ Overview of models and trade name” on page 3-2
9.2 Engine
Engine EZ17
Product Yanmar
Type 3TNV76-SNSE12
Design Water-cooled 3-cylinder diesel engine
Intake system Naturally aspirated engine
fuel injection system Indirect
Engine management Mechanical
Displacement 1116 cm
3
(68.1 in
3
)
Nominal bore and
stroke
76 x 82 mm (2.9 x 3.2 in)
Power
13.4 kW at 2200 rpm
(18 hp at 2,200 rpm)
Max. torque
65.6 Nm at 1600 rpm
(48.4 ft.lbs./1,600 rpm)
Max. engine speed
without load
2200 +/− 25 rpm
(2,200 +/− 25 rpm)
Idling speed
1300 +/− 25 rpm
(1,300 +/− 25 rpm)
Starting aid Glow plugs (preheating time 4 seconds)
Fuel tank 22 liters (5.8 gal)
Exhaust values
according to
EPA – Tier IV final (at fixed point of measure-
ment cycle)
Technical data
