BA EZ17 en* 1.1 * ez17b500.fm 5-1
Operation 5
5Operation
5.1 Steering system
5.2 Accelerator actuation
Manual throttle
The engine speed can be variably set with the throttle lever A.
Movement Drive levers/accelerator pedals
Steering to the left
Steering to the right
Rotation to the left
Rotation to the right
Fig. 73
2
1
A
Engine speed Position
Idling speed 1
Maximum 2
Operation
