Wacker Neuson E16-02 User Manual

BA E16 en* 1.0 * E16_10_300.fm 3-1
Introduction 3
3Introduction
3.1 Machine overview
1
Fig. 2
21
19
2 3 4
13 12
11
20
6
14
10
9
18
17
16
6
7
5
8
15
Item Designation Item Designation
1 Roof light 12 Tie-down points
2 Lifting eye 13 Stabilizer blade
3 Boom light 14 Door handle
4 Boom 15 Handhold
5 Shovel arm 16 Bucket
6 Auxiliary hydraulics 17 Hydraulic quickhitch
7 Rotating beacon 18 VDS console
8 Door arrester 19 Engine cover
9 Hydraulic oil level sight glass 20 Exhaust
10 Cover 21 Cab
11 Chassis -- --
