WAGNER Sprint Airfluid XE User Manual

22
OPERATING MANUAL
VERSION 05/2017 ORDER NUMBER DOC 2354920
SPRINT XE
5.2.3 TECHNICAL DATA
Dimensions:
Height 1,120 mm; 44.10 inch
Width 595 mm; 23.43 inch
Depth 740 mm; 29.13 inch
Weight approx. 40 kg; 88.18 lbs
Maximum box size 420x420x400 mm; 16.54x16.54x15.75 inches
Maximum  lling weight of box 30 kg; 66.14 lbs
Electrical:
Mains (AC) input terminal 90 VAC–250 VAC
Frequency 47 Hz–63 Hz
Input power maximum 110 W
Mains (AC) output terminal Vibrator motor maximum 70 W
Output voltage spray gun maximum 22 Vpp
Output current spray gun Max. 0.9A
Corona current limitation 5 µA–120 µA (adjustable)
Tribo current cut o greater than 12 µA
(ATEX: switching o of the unit)
Pneumatic:
Compressed air connection G1/4"
Connection hose diameter 18.5x12.5 mm
Pressure range input air 0.6–0.8 MPa ; 6–8 bar; 87–116 psi
Air  ow maximum 15 m³/h; 529.63 cf/h
Sum of feed and dosing air 2–12 m³/h; 70.6–423.7 cf/h
Gun air 0.05–4.5 m³/h; 1.765–158.9 cf/h
WAGNER injector type PI-F1, HiCoat ED pump F, PI-F1-S
Compressed air quality according to
ISO 8573.1
6.5.2 according to ISO 8573.1, 2010
WARNING
Exhaust air containing oil!
Risk of poisoning if inhaled.
Insu cient paint application quality
Provide compressed air free from oil and water
(Quality Standard 6.5.2 according to ISO 8573.1, 2010)
6.5.2 = particle density ≤ 5 mg/m; pressure dew point ≤ +7 °C;
oil content ≤ 0.1mg/m
Ambient conditions:
If low-melting powders are used, the ambient temperature may have to be lower than 30 °C;
86 °F.
Volume measures for volumes speci ed in Nm³ (standard cubic meters). One cubic meter
of a gas at 0 °C and 1.013 bar is called norm cubic meter.
