Benchmark Platinum-Edge [ii]: Installation Manual
SECTION 3 – ONAER SETUP
OMM-136_E • GF-210 • 12/13/2019 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 46 of 57
Connecting the Ethernet Cable Instructions
Figure 3-1: Edge Controller – Left Side View
3.1.2 Confirming the Ethernet Connection
Refer to Figure 3-2, below, and complete the following instructions to confirm that the Ethernet
cable connection is working.
Confirming the Ethernet Connection Instructions
1. Powered the unit on and look for the green LED on the Controllers front face above the
onAER soft-key.
2. If the green LED is blinking periodically, there is normal communication with the network.
Figure 3-2: Edge Controller Front Face – Ethernet Indicator LED
GREEN
LED
ETHERNET
JACK
