Welch Allyn TM286 User Manual

40 Program Mode Welch Allyn TM286 Auto Tymp
Program Menu Page 2 Option Descriptions
DATA XFER CONFIG
These settings are used to allow the data transfer from the TM286 to a computer. The
settings must be the same on the TM286 and the computer. The factory defaults are
defined by an *.
POWER UP SETTINGS
The feature determines the mode displayed upon start up. An asterisk will denote which
option is selected to appear on the LCD when the system is first powered up. The factory
default setting is TYMP REFLEX.
PRN HEADER WA/PRN HEADER OFF/PRN HEADER CUSTOM
There are three options for the print header on the printout.
PRINT HEADER WA
This is the factory default setting for this feature. Each time the Print Screen or Print
All tests in memory buttons are pressed, the printout will begin with the label
TM286.
PRINT HEADER OFF
If this option is selected, no header will be printed before any test results, which will save
space and printout time.
PRINT HEADER CUSTOM
Select this option to design a custom header, which might be the name of an individual
facility, department or company. To type in the custom header, position the square cursor
in front of PRN HEADER CUSTOM. Press
to select it as the new default setting.
The word SAVED appears in the lower right corner.
* 115.2 KBAUD * NO PARITY + 8-BIT
57.6 KBAUD ODD PARITY + 7-BIT
38.4 KBAUD EVN PARITY + 7-BIT
17.2 SPC PARITY + 7-BIT
9600 BAUD * XON/XOFF DISABLED
4800 BAUD XON/XOFF ENABLED
TYMP
* TYMP REFLEX
AUDIO
M +
