Owner’s Manual of Lawn Mowing Robot EN
15
8.3
Battery life
The heart of the Landroid
®
is its 20V Li-Ion Battery. For proper storage of the battery, make sure it is fully charged and kept
in a cool dry place between (20°C- 60°C).
NOTE: The recommend Landroid
®
operation temperature is between 0-55°C.
The life-span of the Landroid
®
’s battery depends on various factors, such as:
• The length of the mowing season in your region
• Amount of hours the Landroid
®
mows per day
• Battery maintenance during storage
Landroid
®
can be charged manually without the boundary wire.
1. Connect the Charging Base to a suitable power supply. The green light on the Charging Base will
turn on.
2. Manually dock the Landroid
®
into the Charging Base while the Landroid
®
is powered off. (See Fig. P1)
3. The green light on the Charging Base will turn to red, and the battery indication light will flash
green and red. (See Fig. P2) Landroid
®
will begin to charge.
8.4 Winter hibernation
Your Landroid
®
will live longer and healthier if it is allowed to hibernate. So even though it is tough, we recommend storing
your Landroid
®
in your shed or garage during the winter.
Before you prepare your Landroid
®
for winter hibernation, we recommend you:
• Thoroughly clean your Landroid
®
• Fully charge the battery
• Turn the power off
To maximize the battery life, fully charge the battery before storage during winter.
WARNING: Protect the underside of Landroid
®
from water. NEVER store Landroid
®
upside down
outdoors
The Boundary Wire can be left in the ground although its ends should be protected, such as placed in a tin can with grease.
If the Charging Base is left outside for the winter, leave the Boundary Wire connected.
NOTE: When bringing the Landroid
®
back to work after winter hibernation, make sure the Charging Strips (4) and Contact
Pins (2) are clean. We recommend using a fine grade emery cloth to clean the contacts.
8.5 Replacing the battery
WARNING: Power off before attempting any adjustment, replacement or repair.
Before replacing the Blades, turn your Landroid
®
OFF and put on protective gloves.
If you need to replace the Battery, follow these steps:
1. Gently turn your Landroid
®
upside down.
2. Remove the screws on the battery cover. Remove the battery cover. (See Fig. Q1)
3. Lift out the old battery carefully. Press the latch (a) and release the connectors. (See Fig. Q2)
NOTE: Do not pull by the cables. Hold the connectors and release the latch (a).
4. Connect a new original battery by attaching the connectors until they click into position. (See Fig. Q3, Q4)
5. Fit the battery as shown. (See Fig. Q5) Place the cover back in its position and tighten the screws.
P1 P2
