Xerox C410 User Manual

Moving the Printer to Another Location
CCAAUUTTIIOONN——PPOOTTEENNTTIIAALL IINNJJUURRYY:: If the printer weight is greater than 20kg (44lb), then it may
require two or more people to lift it safely.
CCAAUUTTIIOONN——PPOOTTEENNTTIIAALL IINNJJUURRYY:: To avoid the risk of fire or electrical shock, use only the power cord
provided with this product or the manufacturer's authorized replacement.
CCAAUUTTIIOONN——PPOOTTEENNTTIIAALL IINNJJUURRYY:: When moving the printer, follow these guidelines to avoid personal
injury or printer damage:
• Make sure that all doors and trays are closed.
• Turn off the printer, and then unplug the power cord from the electrical outlet.
• Disconnect all cords and cables from the printer.
• If the printer has separate floor-standing optional trays or output options attached to it, then disconnect them
before moving the printer.
• If the printer has a caster base, then carefully roll it to the new location. Use caution when passing over
thresholds and breaks in flooring.
• If the printer does not have a caster base but is configured with optional trays or output options, then remove
the output options and lift the printer off the trays. Do not try to lift the printer and any options at the same
time.
• Always use the handholds on the printer to lift it.
• Any cart used to move the printer must have a surface able to support the full footprint of the printer.
• Any cart used to move the hardware options must have a surface able to support the dimensions of the options.
• Keep the printer in an upright position.
• Avoid severe jarring movements.
• Make sure that your fingers are not under the printer when you set it down.
• Make sure that there is adequate clearance around the printer.
Note: Damage to the printer caused by improper moving is not covered by the printer warranty.
Xerox
®
C410 Color Printer User Guide 179
Maintenance

Xerox C410 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 4800 DPI
Duplex printing mode	Auto
Print resolution black	1200 x 1200 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.1 s
Time to first page (color, normal)	6.4 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (color, normal quality, A4/US Letter)	20 ppm
PCL fonts	89
Printer fonts	Bitmap, PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	China
Maximum duty cycle	125000 pages per month
Recommended duty cycle	0 - 10000 pages per month
Number of print cartridges	4
Page description languages	PCL 5, PCL 6, PDF 1.7, PostScript 3
Storage media	eMMC
Internal storage capacity	8 GB
Sound power level (printing)	67 dB
Sound pressure level (printing)	52 dB
Sound pressure level (quiet mode)	48 dB
Sound pressure level (duplex printing)	54 dB
USB connector	USB Type-A / USB Type-B
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	FIPS 140-2, TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supported	Windows 10, Windows 11
Total input capacity	251 sheets
Total output capacity	125 sheets
Maximum input capacity	2001 sheets
Paper tray 1 input capacity	1 sheets
Custom media width	98 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Rough paper
Paper tray media weight	60 - 200 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Multi-purpose tray media types	Bond paper, Envelopes, Glossy paper, Heavyweight paper, Labels, Letterhead, Plain paper
Maximum ISO A-series paper size	A4
AC input voltage	220 - 240 V
AC input frequency	47-63 Hz
Power consumption (off)	0.2 W
Power consumption (standby)	22 W
Power consumption (printing)	530 W
Storage temperature (T-T)	-40 - 40 °C
Operating temperature (T-T)	15 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	595 mm
Package width	495 mm
Package height	402 mm
Package weight	23900 g
Cables included	AC
Included cartridge capacity (CMY)	2000 pages
Included cartridge capacity (black)	2400 pages
Display	LCD
Control type	Touch
Product color	Grey, White
Display diagonal	4.3 \
Market positioning	Home & office

Weight and Dimensions

Depth	423 mm
Width	445 mm
Height	318 mm
