Xiaomi Mi Drone User Manual

5
Charging
Charging a quadcopter battery
Connect the battery with a power adapter and plug it into a power
supply as shown below.
During charging indicator blinks to indicate a current charge level.
After full charging lamp does not lit.
Charge level Power button
Note: You may connect battery to adapter from both sides.
Charging the remote control
Connect remote control adapter as
shown above.
During the charging indicator blinks to
indicate the current charge level.
After full charging lamp does not lit.
Charge level
XIAOMI-MI.COM

Xiaomi Mi Drone Specifications

General

Flight Time	27 minutes
Battery Capacity	5100 mAh
GPS	Yes
Gimbal	3-axis
Max Speed	18 m/s
Transmitter Frequency	2.4 GHz
Return to Home	Yes
Follow Me Mode	Yes
Obstacle Avoidance	No
Operating Temperature Range	40°C
Satellite Positioning Systems	GPS, GLONASS
Video Resolution	4K
Max Transmission Distance	4 km
Model	Mi Drone
