VB3/V5/VB5 series inverter
12
1-4. Product dimension
VB3 series 0.4~0.75KW (Unit: mm)
VB3, VB5 series 0.75~3.7KW (Unit: mm)
The details of the dimension:
Type W D1 L D2 H
VB5-20P7
70 56 170 160 162 VB5-21P5
VB5-22P2
VB3/VB5-40P7
80 56 200 190 162
VB3/VB5-41P5
