V5 series inverter
85
PB.01 Dead zone time of forward/reverse running Range: 0,1 0
0: Always valid. Based on the value set in P0.05, the minimum value is 0.1s.
1: The time can be set to 0（no dead time）.You should set P0.05=0.0s, P0.20≥0.5Hz.
This function is usually used to the continuous to-and-for control. If swift turn-around is needed, reduce the Acc/Dec time and
increase the lower limit frequency/start frequency.（P0.17≤0.5s, P0.18≤0.5s, P0.20≥2.0Hz, P2.01≥2.0Hz）.
PB.02 Inverter type select Range: 0, 1 0
0: G type (general type), fit for normal situation.
1: P type (fans,water pump), fit for fans, water pump and other small load situation. In this mode, power will improve 1
level, if the machine power is 2.2KW, in P type mode, the power will improve to 3.7KW. Please note P0.22 should be set to 3.
PB.03 Run mode Range: 0,1 1
0: before power on, if the terminal is short, run the inverter immediately.
1: before power on, if the terminal is short, run the inverter after cut off the terminal and connect it again.
4-2-13. Default setting and password (Group PF)
PF.00 Default password
－ －
PF.01 User password Range: 0000~9999 0000
This parameter can prohibit the unauthorized personnel from viewing or modifing function parameters.
Please set it to 0000 if don’t need user password.
If usre password is needed, input four figures as password, then press to confirm, the password will be valid im-
mediately.
Modification: Press key to validate password, input correct password to enter parameter editing status. Choose
PF.01 (PF.01=0000), input new password and press to confirm, then the password will be valid immediately. The
password for super user is 2644.
PF.02 Software version
－ －
Software version is set by Xinje company, cannot be changed.
