4
SYMBOLS USED
L=R
2x
CA
OIL
CORRECT WRONG
Overtightened
The threads
are stripped.
Part bags used Assemble left and right
sides the same way
Assemble in the specified
order
Pay attention here Assemble as many times
as specified (here twice)
Apply CA glue
TOOLS REQUIRED
EQUIPMENT REQUIRED
EQUIPMENT INCLUDED
Apply oil Use pliers
XRAY Premium Silicone
Oil 350cSt (#359235)
Side Cutters
(HUDY #189010)
Hobby Knife Turnbuckle 3mm, 4mm
(HUDY #181030,
HUDY #181040)
Reamer
(HUDY #107600)
Combination Pliers
(HUDY #189020)
Snap Ring Pliers
(HUDY #189040)
HUDY TOOLS: Allen: 1.5mm, 2.0mm, 3.0mm
Socket: 5.5mm, 7.0mm
Transmitter Steering ServoReceiver
Diff. Grease
(HUDY #106211)
TL
05
Tighten screw
gently
Apply thread lock
Lexan Paint Battery Charger Wheels & Tires & Inserts
Apply grease Ensure smooth
non-binding movement
2.0 mm
3.0 mm
1.5 mm
7.0 mm
5.5 mm
Graphite Grease
(HUDY #106210)
Bearing Oil
(HUDY #106230)
Follow Set-Up Book
FRONT & REAR AXLES
Scissors
(HUDY #188990)
3.0 mm
4.0 mm
CONTENTS
Speed Controller
5-cell or 6-cell Battery Pack
(Inline)
Pinion Gear and Setscrew
190mm Bodyshell
Electric Motor &
Fibre Tape (HUDY #107870)
Double-sided Tape
WARNINGS
2-3
TOOLS AND ACCESSORIES
4
0. KIT
5
1. BALL DIFFERENTIAL & FRONT SOLID AXLE
6-7
2. FRONT & REAR SUSPENSION
8-10
3. CENTRAL TRANSMISSION
11-13
4. STEERING
14-15
5. FRONT & REAR TRANSMISSION
16-21
6. SHOCK ABSORBERS
22-24
7. FRONT & REAR ASSEMBLY
25-27
8. FINAL ASSEMBLY
28-30
BALANCING CONFIGURATION
31
