Xtool IP508S User Manual

I
Please read this user manual carefully before using the IP508S Smart Diagnostic System, referred to as the “Scan Tool”
throughout this document. When reading the manual, please pay attention to the words “Note” or “Caution”, and read them
carefully for appropriate operation.
OPERATION INSTRUCTIONS
For safe operation, please follow the instructions below:
⚫ Keep the device away from heat or fumes when in use.
⚫ If the vehicle battery contains acid, please keep your hands and skin or fire sources away from the battery during
testing.
⚫ The exhaust gas of the vehicle contains harmful chemicals. Please ensure adequate ventilation.
⚫ Do not touch the vehicle cooling system components or exhaust manifolds when the engine is running due to the high
temperatures reached.
⚫ Make sure the car is securely parked, Neutral is selected or the selector is at the P or N position to prevent the vehicle
from moving when the engine starts.
⚫ Make sure the (DLC) Diagnostic Link Connector is functioning properly before starting the test to avoid damage to the
Diagnostic Computer.
⚫ Do not switch off the power or unplug the connectors during testing. Doing so may damage the ECU (Electronic
Control Unit) and/or the Diagnostic Computer.
CAUTIONS!
⚫ Avoid shaking, dropping or dismantling the scan tool as it may damage the internal components.
⚫ Use only your fingertips to touch the LCD screen. Hard or sharp objects may damage the scan tool.
⚫ Do not use excessive force;
⚫ Do not expose the screen to strong sunlight for a long period.
⚫ Please keep the scan tool away from water and moisture.
⚫ Store and use the scan tool only within the temperature ranges identified in the Technical Specifications section.
⚫ Keep the unit away from strong magnetic fields.
AFTERSALES-SERVICES
XTOOL strives to provide best-in-class support!
E-Mail: support1@xtooltech.com (for Amazon) | support2@xtooltech.com (for Ali-Express, eBay and others)
Tel: +86 755 21670995 or +86 755 86267858 (China)
Official Website: www.xtooltech.com | www2.xtooltech.com (Alternate sites)

Xtool IP508S Specifications

General

Operating System	Android
Processor	Quad-Core
Connectivity	Wi-Fi
Diagnostic Protocols	OBD2
Storage	16G
Weight	500g
Languages Supported	Multiple languages

Summary

OPERATION INSTRUCTIONS

CAUTIONS!

GENERAL INTRODUCTION

GETTING STARTED

CONNECTING POWER

ACTIVATION

DIAGNOSTIC

VEHICLE CONNECTION

Procedure for connecting the scan tool to the vehicle's OBD-II port for communication.

BEGINNING DIAGNOSTIC TESTING

Steps to initiate the vehicle diagnosis process after connection.

VEHICLE SELECTION

Methods to select a vehicle for diagnosis: AUTO SCAN, MANUAL INPUT, or AREA.

Diagnosis functions

Details the diagnostic capabilities like reading ECU info, DTCs, live data, and freeze frame.

SPECIAL FUNCTIONS

ABS BLEEDING

Procedure to bleed the ABS system to restore brake sensitivity and performance.

OIL RESET

Resets the engine oil life system based on driving conditions and climate.

EPB

Resets the electronic parking brake system, including brake pads and sensors.

SAS

Calibrates the Steering Angle Sensor, essential after steering system repairs.

THROTTLE

Sets initial throttle actuator settings and returns learned values to default.

BMS RESET

Evaluates battery charge state and registers battery replacement.

INJECTOR CODING

Writes injector identification codes into the ECU for accurate fuel injection.

DPF REGENERATION

Clears PM from DPF filter via continuous combustion oxidation mode.

TPMS RESET

SETTINGS

REPORT

REPORT

Data Playback

UPDATE & FACTORY RESET

UPDATE

FACTORY RESET

FAQ

REMOTE ASSISTANCE

REMOTE ASSISTANCE
