Number Part Product name Description
2 Controller APP 412 • Based on process conditions, the
controller regulates the mixer.
• The operator changes the mixer settings
through the local HMI or through a SCADA
system over Modbus.
• Data is logged by and stored in the
controller.
• All the alarms are available on the local
HMI and Modbus.
• System communication through the
backplane.
3 Gateway FPG 415 A gateway that is controlled by APP 412
• System communication through the
backplane.
• All the alarms and data are sent to the
controller.
4 HMI FOP 402 HMI - Alternative 1
• A touchscreen HMI that is used for
navigation and selection in the menus.
• The touchscreen HMI is connected to a
web server that is embedded in the
controller.
5 HMI FOP 315 HMI - Alternative 2
• A basic HMI with a jog wheel that is used
for navigation and selection in the menus.
6 Computer – HMI - Alternative 3
• The computer gives access to the same
menu system as the touchscreen HMI.
• The computer is connected to a web server
that is embedded in the controller.
7 Cloud connection – Cloud services
8 Connection to power – Contactors, fuses, relays
9 Extended I/O
module
FPG 415 A gateway that is used as an extended I/O
module
2.2 Adaptive ultra-low head propeller pumps ADC
The system consists of one to eight pumps, with one APP 412 controller and
one FPG 415 gateway for each additional pump.
2 System Description
8 APP 412 Installation, Operation, and Maintenance manual
