Codes and parameters
XXYYYY YYY YYY YYYY
1
2
3
4
5
6
7
a
b
c
WS006265B
.
Type of Callout Number Indication
Type of code a Sales denomination
b Product code
c Serial number
Parameter 1 Hydraulic end
2 Type of installation
3 Sales code
4 Version
5 Production year
6 Production cycle
7 Running number
4.2 The gateways
4.2.1 Product design
The products are part of the Concertor
™
system.
Menus for configuration, performance data and statistics, and alarms are accessible
through the Flygt FOP 312 HMI, through I/O, or through Modbus RTU.
Product name Part number Description
FPG 411 8012100 Gateway for Concertor
™
EA
FPG 412 8012000 Gateway for Concertor
™
DP
FPG 411
The gateway allows control of the pump through digital input .
The pump performance curve can be changed when the pump is stopped, through the
HMI or through Modbus RTU.
An external HMI can be connected to monitor all pump data.
FPG 412
The gateway allows variable performance control of the pump through a 4-20 mA analog
signal, or through Modbus RTU.
An external HMI can be connected to monitor all pump data.
4.2.2 Approvals
• CE
• UL
• CSA
• RCM
4 Product Description
Concertor
™
6020 Installation, Operation, and Maintenance Manual 17
