5.2 Requirements
General requirements
• Use the dimensional drawing to make sure that the installation is correct.
• Always remove all debris and waste materials from the sump and piping before
installation.
Piping requirements
NOTICE:
Never force piping to make a connection with a pump.
5.3 Make the mechanical installation
5.3.1 Prepare the site: new P-installation
For more information, see the separate accessories documentation.
1. Install the upper guide bar holder.
2. Prepare the base for the discharge connection.
Make sure that the following requirements are fulfilled:
– The base is aligned horizontally.
– The anchor bolts are installed correctly.
– The integrated lower guide bar support that is part of the discharge connection can
be vertically aligned with the upper guide bar holder.
3. Put the discharge connection in position, and tighten the nuts.
4. Install the guide bars.
5. Connect the discharge pipe to the discharge connection.
6. Install the cable holders where they are needed.
5 Mechanical Installation
20 Concertor
™
6020 Installation, Operation, and Maintenance Manual
