RF-IF -9

Parts List

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

RF-IF Unit

FT-450 Series Technical Supplement

PCB with Components CB3663001

Printed Circuit Board FR015290C 1-

Printed Circuit Board FR015290D 16-

C 2001 CHIP CAP. 0.1uF 50V B GRM42-6B104K50PT K22171820 1- A A2

C 2002 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A A2

C 2002 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A A2

C 2003 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A A2

C 2003 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A A2

C 2004 CHIP CAP. 0.0039uF 50V B GRM188B11H392KA01D K22174830 1- A B2

C 2005 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A A2

C 2005 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A A2

C 2006 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A B3

C 2007 CHIP CAP. 0.0022uF 50V B GRM188B11H222KA01D K22174813 1- A B2

C 2008 CHIP CAP. 0.0015uF 50V B GRM188B11H152KA01D K22174811 1- A B1

C 2009 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A B2

C 2010 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A B3

C 2010 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A B3

C 2011 CHIP CAP. 0.0056uF 50V B GRM188B11H562KA01D K22174818 1- A B2

C 2012 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- A C6

C 2012 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 14- A C6

C 2013 CHIP CAP. 0.0022uF 50V B GRM188B11H222KA01D K22174813 1- A B2

C 2014 CHIP TA.CAP. 1uF 16V TEESVA1C105M8R K78120009 1- A C6

C 2015 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A B2

C 2015 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A B2

C 2016 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A B3

C 2016 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A B3

C 2017 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A C6

C 2018 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A C6

C 2018 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A C6

C 2019 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A B2

C 2019 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A B2

C 2020 CHIP TA.CAP. 1uF 16V TEESVA1C105M8R K78120009 1- A B2

C 2021 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A B2

C 2021 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A B2

C 2022 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D6

C 2022 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D6

C 2023 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A B1

C 2023 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A B1

C 2024 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A D6

C 2025 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A D6

C 2026 CHIP TA.CAP. 2.2uF 16V TEESVA1C225M8R K78120015 1- A A3

C 2027 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D6

C 2027 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D6

C 2028 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C6

C 2029 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A B1

C 2029 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A B1

C 2030 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A D6

C 2031 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A C6

C 2032 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A D6

C 2033 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A D6

C 2034 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- A B1

C 2034 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 14- A B1

C 2035 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A D6

C 2036 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D6

C 2036 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D6

C 2037 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A B1

C 2037 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A B1

C 2038 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A C6

C 2039 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A B1

C 2039 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A B1

C 2040 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A C6

C 2040 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A C6

C 2041 CHIP TA.CAP. 1uF 16V TEESVA1C105M8R K78120009 1- A B1

C 2042 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- A D6

C 2043 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A B3

C 2043 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A B3

C 2044 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A B3

C 2044 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A B3

C 2045 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A B2

C 2045 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A B2

C 2046 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A B2

C 2046 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 14- A B2

C 2047 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A B2

Receiver Type	Triple-conversion superheterodyne
Supply Voltage	13.8 V DC ±15%
Current Consumption Max	22 A
Frequency Range Receive	30 kHz - 56 MHz
Modes	SSB, CW, AM, FM
Power Output	100 W
Antenna Impedance	50 Ohms
Current Drain Transmit	22 A
Weight	3.6 kg
Output Power 50MHz	100 W
