CNTL-9

Parts List

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

CNTL Unit

FT-450 Series Technical Supplement

PCB with Components (FT-450) CS1923014 USA

PCB with Components (FT-450) CS1923015 EXPORT

PCB with Components (FT-450) CS1923016 EUROPE

PCB with Components (FT-450) CS1923017 UNITED KINGDOM

PCB with Components (FT-450) CS1923018 FRANCE

PCB with Components (FT-450) CS1923019 AUSTRALIA

PCB with Components (FT-450D) CS1923023 USA

PCB with Components (FT-450D) CS1923024 EXPORT

PCB with Components (FT-450D) CS1923025 EUROPE

PCB with Components (FT-450D) CS1923026 UNITED KINGDOM

PCB with Components (FT-450D) CS1923027 FRANCE

PCB with Components (FT-450D) CS1923028 AUSTRALIA

Printed Circuit Board FR015300C 1-

Printed Circuit Board FR015300D 16-

C 4001 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A H3

C 4001 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A H3

C 4002 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A H3

C 4002 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A H3

C 4006 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D3

C 4006 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D3

C 4007 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A H3

C 4007 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A H3

C 4008 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D1

C 4008 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D1

C 4011 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A H3

C 4011 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A H3

C 4012 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D1

C 4012 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D1

C 4015 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A H3

C 4015 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A H3

C 4016 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D1

C 4016 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D1

C 4019 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A H3

C 4019 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A H3

C 4020 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D1

C 4020 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D1

C 4021 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A E1

C 4021 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A E1

C 4023 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A G3

C 4023 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 6- A G3

C 4024 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D1

C 4024 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D1

C 4025 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A E1

C 4025 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A E1

C 4027 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A G3

C 4027 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 6- A G3

C 4028 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D1

C 4028 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D1

C 4029 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A E1

C 4029 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A E1

C 4030 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G3

C 4031 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G4

C 4033 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A E1

C 4033 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A E1

C 4034 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G3

C 4035 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G3

C 4036 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D1

C 4036 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D1

C 4037 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A E1

C 4037 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A E1

C 4038 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D1

C 4038 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D1

C 4039 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A E1

C 4039 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A E1

C 4040 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A D1

C 4040 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A D1

C 4042 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A A2

C 4042 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A A2

C 4043 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A A2

C 4043 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 14- A A2

C 4044 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A J2

C 4045 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A G1

C 4045 CHIP TA.CAP. 22uF 4V TEESVP0G226M8R K78060047 5- A G1
