SPECIFICATINS
GENERAL RECEIVER
Frequency range: Circuit type:
see Model Chart Double-conversion superhet
Channel steps Intermediate frequencies:
5/10/12.5/20/25 kHz 45 MHz & 455 kHz
Standard repeater shift: Sensitivity (for 12dB SINAD):
see Model Chart better than 0.18uV
Mode of emission: Image ratio:
G3E better than 65dB
Antenna impedance: Selectivity (-6/-60dB)
50 ohms, unbalanced 12/30 kHz
Supply voltage: Audio Output (for 5% THD):
13.8 VDC ±10%, neg. Ground at least 1.5W into 8 ohms
Supply current:
Transmit 35W: 10A TRANSMITTER
Receive: 500mA
Standby: 300mA RF output power (50 ohms):
3 watts and 35 watts
Operating temp. range:
-20 to +60 °C Modulation method:
Variable reactance
Frequency accuracy:
±5ppm (-5° to +50°C) Maximum deviation:
±5 kHz
Case size (WHD):
140 x 40 x 160mm Spurious emissions:
at least 60 dB below carrier
Weight:
Approx. 1.25 kg Microphone impedance:
2 kilohms
Specification subject to change without notice.
-3-
