Load Weight In Pounds (lb) Icon
Load Weight In Kilograms (kg) Icon
Load Weight Readout (example)
System Time Readout (example)
Password Screen Icons
The Password Screen has only one icon, which is shown in Table 7. If the truck is equipped with Operator
Passwords enabled, the Password Screen is the first screen to appear when you turn on the key switch or turn
the keyless switch to the ON position. See the Passwords Screen topic for more information.
Table 7. Password Screen Icons
Icon Description
Password Lock Icon
A field with five blanks appears below the Password Lock Icon. See Figure 2.
Activity Log Submenu Icons
Table 8 presents the icons that appear on the Activity Log Submenus. These icons provide status information
or numeric information. Refer to Activity Log Menu for more information.
Table 8. Activity Log Submenus and Icons
Icon Description
Activity Log Submenus
To Next Page
