DIGITAL NETWORK PREMIUM GAUGE RIGGING KIT CONTENTS
TWIN ENGINE PREMIUM GAUGE KIT
P/N: 6Y9-W0035-15
TRIPLE ENGINE PREMIUM GAUGE KIT (FOR EU, ANZ, GEN)
P/N: 6Y9-W0035-43
MAIN HELM SW PANEL TWIN ENGINE KIT (FOR US, CAN)
P/N: 6X6-W0035-50
Part No. Part name Q’ty Remarks
6Y9-83710-11 Premium gauge ASSY 1 5" color display, w/ screen cover
6Y8-81920-01 Multi-hub 1 w/ resistor cap
6Y8-82582-11 4-pin waterproof cap 2 White
6Y8-82553-01 Main bus wire, 0.3 m (1 ft) 1
6Y8-82521-31 Pigtail bus wire, 1.8 m (6 ft) 1
6Y9-83553-40 Conversion harness, 0.15 m (0.5 ft) 1 Hub to premium gauge
6Y9-83553-00 Conversion harness, 0.3 m (1 ft) 1 RC to hub
6Y8-83553-01 PWR supply wire 1 w/ 10 amp fuse
6Y9-8356N-01 GPS wire 1 NMEA0183
6Y9-8356N-10 Fuel tank wire 1 4 fuel tanks acceptable
6X6-82570-40 IG switch, twin 1 OFF-ON
6X6-82570-60 Start/stop SW, twin 1
6X6-8258A-40 Main wire-harness, 12.2 m (40 ft) 2 16-pin
6Y9-2819K-E0 Set up manual 1
6Y9-2819U-72 Instruction 2 1
6Y9-2819U-82 Instruction 3 1
Part No. Part name Q’ty Remarks
6X6-2819K-E0 Setup manual 1
6X6-82570-50 IG switch panel, Main helm 1
6X6-82570-70 Start/stop SW panel, Main helm 1
6X6-8258A-40 Main wire-harness, 12.2 m (40 ft) 3 16-pin
6Y8-81920-01 Multi-hub 1
6Y8-82521-31 Pigtail bus wire, 1.8 m (6 ft) 1
6Y8-82553-01 Main bus wire, 0.3 m (1 ft) 1
6Y8-82582-11 4-pin waterproof cap 2 White
6Y8-83553-01 PWR supply wire 1 w/ 10 amp fuse
6Y9-83553-00 Conversion harness, 0.3 m (1 ft) 1 RC to hub
6Y9-83553-40 Conversion harness, 0.15 m (0.5 ft) 1 Hub to premium gauge
6Y9-8356N-01 GPS wire 1 NMEA0183
6Y9-8356N-10 Fuel tank wire 1 4 fuel tanks acceptable
6Y9-83710-11 Premium gauge ASSY 1 5" color display, w/ screen cover
6Y9-2819U-71 Instruction 2 1
6Y9-2819U-81 Instruction 3 1
Part No. Part name Q’ty Remarks
6X6-82570-40 IG switch, twin 1 OFF-ON
6X6-82570-60 Start/stop SW, twin 1
