2-6
PROPELLER SELECTION
Depending on the model, Yamaha outboard motors are fitted with the propellers which are chosen
to perform well over a range of applications, but there may be the uses where a propeller with a dif-
ferent pitch would be more appropriate.
For a greater operating load, a smaller pitch propeller is more suitable as enables the correct engine
speed at WOT (Wide-Open-Throttle) to be maintained.
Conversely, a larger pitch propeller is more suitable for a smaller operating load.
For details, see the WOT operation range table in this chapter.
Besides, select the best matched propeller series that meet the purpose of use depending on the
classification and/or type of boat.
2014 PROPELLER APPLICATIONS
STANDARD PROPELLER
2 ps
2 – 3 ps
* Use the thrust washer (68D-G5987-00) for 4-stroke mode, and (6L5-45987-01) for 2-stroke model.
4 – 6 ps
Global model 2C
US/CA model
Blade Dia. (in) Pitch (in) Mark Material Part number Remarks
3 7 1/4 4 A Plastic 6A1-45943-00 Fitted with shear pin
3 7 1/4 4 1/2 A Aluminum 646-45944-01 Fitted with shear pin
3 7 1/4 5 A Aluminum 6F8-45942-01 Fitted with shear pin
3 7 1/4 5 1/2 A Aluminum 646-45942-01 Fitted with shear pin
Global model F2A F2.5A 3A
US/CA model F2.5A
Blade Dia. (in) Pitch (in) Mark Material Part number Remarks
3 7 1/4 5 BS Aluminum 6L5-45949-00
3 7 1/4 5 1/2 BS Aluminum 6L5-45952-00
3 7 1/4 6 BS Aluminum 6L5-45943-00
3 7 1/4 7 1/4 BS Aluminum 6L5-45945-00
3 7 1/4 8 1/4 BS Aluminum 6L5-45947-00
Global model 4AC 5C 5CS F4B F5A 5CM F6C
US/CA model F4A F6A
Blade Dia. (in) Pitch (in) Mark Material Part number Remarks
3 7 1/4 6 1/2 BA Aluminum 6E0-45949-00
3 7 1/2 7 BA Aluminum 6E0-45943-01
3 7 1/2 8 BA Aluminum 6E0-45941-01
3 7 1/4 8 1/4 BA Aluminum 6E0-45952-00
3 7 1/2 9 BA Aluminum 6E0-45954-00
