4-1
E
DIMENSIONS
PERFORMANCE
8Overall Length mm (in.)
8Overall Height S/L/X mm (in.)
8Overall Width mm (in.)
8Transom height S/L/X mm (in.)
8Weight S/L/X kg (lb.)
802 (31.6)
977 (38.5)/1,104 (43.5)/1.167 (45.9)
342 (13.5)
436 (17.2)/563 (22.2)/626 (24.6)
27 (59.4)/27.5 (60.5)/28 (61.7)
8Full throttle operating range r/min
8Maximum output kW (HP)
8Idling speed (in neutral) r/min
4,500~5,500
5.9 (8) at 5,000 r/min.
850~950
ENGINE
8Engine type
Displacement cm
3
(cu.in.)
Bore × stroke mm (in.)
8Ignition system
8Spark plug NGK
Spark plug gap mm (in.)
8Control system
8Starting system
8Battery capacity V-AH (kc)
Minimum cold crank peformance Amps at -17.8°C (0°F)
Minimum reserve capacity minutes at 26.7°C (80°F)
8Alternator output V-A (W)
8Starting carburetion system
2-stroke, L2
165 (10.01)
50 × 42 (1.97 × 1.65)
C.D.I
B7HS-10
0.9~1.0 (0.035~0.039)
Tiller control
Manual start
–
–
–
12-(80)
Choke valve start system
EMR50302
SPECIFICATION DATA
Model
Unit 8MHA
Item
DRIVE UNIT
8Gear positions
Gear ratio
8Trim/tilt system
8Propeller mark
Forward-Neutral-Reverse
2.08 (27/13)
Manual
N
FUEL AND OIL
TIGHTENING TORQUE
8Fuel
Fuel tank capacity L (US gal, Imp gal)
8Recommended engine oil
Fuel/oil ratio
8Recommended gear oil
Gear oil quantity cm
3
(US oz, Imp oz)
Regular unleaded gasoline
(P.O.N.: minimum 86)
25 (6.6, 5.5)
YAMALUBE 2 STROKE OUTBOARD OIL or an
equivalent TC-W3 certified outboard oil
100 : 1
Hypoid gear oil (SAE 90)
160 (5.41, 5.63)
25 (2.5, 18)
17 (1.7, 12)
8Spark plug N•m (kgf•m, lb•ft)
8Propeller nut N•m (kgf•m, lb•ft)
