Yamaha AR210 Owner's Manual

2-13
dealer check the engine oil pres-
sure.
NOTE: All three warning indicators
blink when the No-Wake Mode system
is engaged (see page 2-15).
OVERHEAT WARNING SYSTEM
The engine has an overheat warning
device. If either engine starts to over-
heat, the engine speed of the affected
engine will be limited to 3000 rpm.
Each engine is equipped with cooling-
water pilot outlets 1 on the starboard
side of the hull. Check that water
comes out of the outlet while the
engine is running, particularly while
applying throttle. If you do not see any
water at the outlet, cooling water may
not be circulating in the engine.
NOTE: If water cooling passages on
the engines are dry, it will take about 20
seconds for water to reach the pilot out-
lets after starting.
If water is not circulating, something
may be clogging the jet intake grate.
Refer to the Jet Pump Clean-Out pro-
cedures on page 5-5 for further infor-
mation.
If the cause of overheating cannot
be found and corrected, take special
precautions to avoid major engine
damage while you return to shore.
SINGLE ENGINE OVERHEATING
—
Shut off the overheating engine and
use the properly running engine to
return to shore. Operate at “no-
wake” speed to prevent water from
flooding the non-operating engine
through the cooling water intake.
See page 2-15 for “No Wake Mode”
system operation.
BOTH ENGINES OVERHEATING —
If getting a tow from another vessel
is not possible, operate both
engines just slightly above idle
while you return to shore. If you can
be towed, refer to “Towing the boat”
on page 5-3.
FEATURES & FUNCTIONS 2
CAUTION:
1
0
1
2
3
4
5
6
7
8
9
1
0
2
0
3
0
3
5
4
0
4
5
5
0
5
5
6
0
MPH
RPM
x 1000
0
2
3
4
5
6
7
8
9
RPM
x 1000
Fuel
f
e
YAMAHA
YAMAHA
YAMAHA
YAMAHA
DEPTH

Yamaha AR210 Specifications

General

Length	21' 3"
Beam	8' 6"
Fuel Capacity	50 gallons
Storage Capacity	Multiple storage compartments
Seating Capacity	10 persons
Passenger Capacity	10 persons
