Yamaha AR210 Owner's Manual

FRONT WALK-THROUGH
If desired, the Walk-Through to the bow
of the boat can be closed.
Doorway
Unlatch the door from the port-side
console storage compartment, and lock
it into place on the driver's side con-
sole.
To open the doorway, unlatch the door
from the driver's side console and lock
it into place on the port-side storage
compartment.
Windshield
Unsnap the retaining strap 1 from the
windshield and pivot it into place.
Rotate the two latches 2 to keep the
windshield secured. When the wind-
shield is open, be sure to secure it with
the retaining strap to keep it from mov-
ing while underway or trailering.
To avoid injury, window must be
secured when vessel is in motion.
2-19
FEATURES & FUNCTIONS 2
1
2
2
WARNING

Yamaha AR210 Specifications

General

Length	21' 3"
Beam	8' 6"
Fuel Capacity	50 gallons
Storage Capacity	Multiple storage compartments
Seating Capacity	10 persons
Passenger Capacity	10 persons
