MPX100
II
SERIES
MPX100II
PARTS LIST
CONTENTS
ELECTRICAL PARTS 1~6
OVERALL ASSEMBLY 8
CONTROL UNIT 12
PANEL UNIT 13
HAMMER SENSOR UNIT 15
MN UNIT 16
SWITCH BOX ASSEMBLY 17
PEDAL SENSOR UNIT 18
PEDAL DRIVE UNIT 19
MOTOR DRIVE UNIT 21
SUB-POWER SUPPLY UNIT 22
AC CORD ASSEMBLY 23
For the following sections of the parts list in the service manual, please
refer to the MX100II service manual(008659).
Mechanical parts
KEY SENSOR UNIT, KEY DRIVE UNIT
Electrical parts
Circuit boards(CONTROL OUT, CONNECTION, PANEL SWITCH,
HAMMER EMISSION, KEY RECEIVE, KEY EMISSION, DRIVE A,
DRIVE B. DRIVE C), POWER SUPPLY UNIT
Notes: Destination Abbreviations
U: US model
C: Canadian model
E: European model
A: Australian model
B: British model
•The numbers with "pc." or "pcs" in "Remarks" show quantities for each unit.
•The parts with "-" in "Parts No." are not available as spare parts.
