4-1
E
EMU01871¯
SPECIFICATIONS
Model
Unit F200TRC
DIMENSIONS
Overall length mm (in.) 892 (35.1)
Overall width mm (in.) 634 (25.0)
Overall height X/U mm (in.) 1,805 (71.1)/–
Transom height X/U mm (in.) 643 (25.3)/–
Weight* X/U kg (lb.) 265 (584)/–
PERFORMANCE
Full throttle operating range r/min 5,000–6,000
Maximum output kW (HP) @ r/min 147.1 (200) @ 5,500
Idling speed (in neutral) r/min 650–750
ENGINE
Type 4-stroke, DOHC, V6
Displacement cm
3
(cu.in.) 3,352 (204.54)
Bore
×
stroke mm (in.) 94.0
×
80.5 (3.70
×
3.17)
Ignition system TCI system
Spark plug NGK LFR5A-11
Spark plug gap mm (in.) 1.0–1.1 (0.039–0.043)
Control system Remote control
Starting system Electric start
Valve clearance (cold engine) IN mm (in.) 0.17–0.23 (0.007–0.009)
EX mm (in.) 0.31–0.37 (0.012–0.015)
Battery
Min. cold cranking amps (CCA/SAE) amps at -18°C (-0.4°F) 512
Min. marine cranking amps (MCA/ABYC) amps at 0°C (32°F) 675
Min. reserve capacity (RC/SAE) minutes 182
Alternator output V-A (W) 12-45
Starting carburetion system Electronic fuel injection
DRIVE UNIT
Gear positions Forward-Neutral-Reverse
Gear ratio 2.00 (30/15)
Trim and tilt system Power trim and tilt
Propeller mark T/M
FUEL AND OIL
Recommended fuel Regular unleaded gasoline
P.O.N. Minimum 86
Fuel tank capacity L (US gal, Imp gal) —
Recommended engine oil 4-stroke motor oil
API SE, SF, SG, SH, SJ
SAE 10W-30, 10W-40
Engine oil capacity (excluding oil filter) L (US qt, Imp qt) 5.8 (6.13, 5.1)
(including oil filter) L (US qt, Imp qt) 6.0 (6.34, 5.3)
Recommended gear oil Hypoid gear oil (SAE90)
Gear oil capacity cm
3
(US oz, Imp oz) 1,150 (38.88, 40.56)
TIGHTENING TORQUE
Spark plug N·m (kgf·m, lb·ft) 25 (2.5, 18)
Propeller nut N·m (kgf·m, lb·ft) 55 (5.5, 40)
Engine oil drain bolt N·m (kgf·m, lb·ft) 27 (2.7, 20)
Engine oil filter N·m (kgf·m, lb·ft) 18 (1.8, 13)
* Listed weight does not include propeller.
