8-19
DIGITAL NETWORK GAUGE RIGGING KIT CONTENTS
ROUND STYLE GAUGE RIGGING KIT FOR EUROPE
SINGLE KIT 1 (TACH)
Kit P/N: 6YR-W0035-Y1
SINGLE KIT 1 (TACH) w/o Transom Wire Harness
Kit P/N: 6Y8-W0035-00
Part No. Part Name Q’ty Remarks
6Y8-82521-41 Pigtail bus wire, 9 ft 1
6Y8-82553-21 Main bus wire, 20 ft 1
6Y8-81920-11 Single-hub 1 With resistor
6Y8-82521-11 Pigtail bus wire, 2 ft 1
6Y8-81920-01 Multi-hub 1 With resistor cap, GRY
6Y8-82582-11 4-pin cap 2 For waterproof
6Y8-8350T-11 RND tachometer 1
6Y8-83553-01 PWR supply wire, 8 ft 1 With 10 amps fuse
Part No. Part Name Q’ty Remarks
6Y8-82521-11 Pigtail bus wire, 2 ft 1
6Y8-81920-01 Multi-hub 1 With resistor cap, GRY
6Y8-82582-11 4-pin cap, WHT 2 For waterproof
6Y8-8350T-11 RND tachometer 1
6Y8-83553-01 PWR supply wire, 8 ft 1 With 10 amps fuse
To Next Page
