Electrical characteristics
276
LS9-16/32 Owner’s Manual
❏ Crosstalk@1kHz
❏ Maximum Voltage Gain@1kHz
❏ Phantom Voltage
From To Conditions Min. Typ. Max. Unit
INPUT n INPUT (n-1) or (n+1) CH 1-16 {1-32}, Adjacent inputs, GAIN: min. -80
dB
OMNI OUT n OMNI OUT (n-1) or (n+1) OMNI OUT 1-8 {1-16}, Input to output -80
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-16 <LS9-16>
INPUT 1-32 <LS9-32>
OMNI OUT 1-8 <LS9-16>
OMNI OUT 1-16 <LS9-32>
600 Ω Rs=150Ω, Input GAIN: max. 86 dB
Output Conditions Min. Typ. Max. Unit
INPUT 1-16 <LS9-16>
INPUT 1-32 <LS9-32>
hot & cold: No load 46 48 50 V
