MG16/6FX
3
■ SPECIFICATIONS
■ General Specifications
1
Rs = 150 ohms
Measured with 12.7 kHz, -6 dB/oct. low pass filter (equivalent to 20 kHz, -∞ filter).
(CH MIC INPUT to ST, GROUP OUT/AUX, EFFECT SEND)
2
Turning PAN/BAL to left or right.
3
Shelving turnover/rolloff frequency: 3 dB before maximum cut or boost.
Where 0 dBu = 0.775V and 0 dBV = 1 V
Frequency Characteristics (ST OUT) 20 Hz-20 kHz +1 dB, -3 dB @+4 dBu, 600 Ω (with gain control at maximum level)
Total Harmonic Distortion (ST OUT) 0.1% (THD+N) @+14 dBu, 20 Hz-20 kHz, 600 Ω (with gain control at maximum level)
-128 dBu Equivalent input noise (CHs 1 to 8)
-100 dBu Residual output noise (ST OUT)
-88 dBu (92 dB S/N) ST, GROUP Master fader at nominal level; all Ch assign switches off.
Hum and Noise
1
-81 dBu (85 dB S/N)
AUX, EFFECT master control at nominal level; all channel mix con-
trols at minimum level.
-64 dBu (68 dB S/N)
ST, GROUP Master fader and one Ch fader at nominal level.
(CHs 1 to 8)
60 dB CH MIC INPUT → CH INSERT OUT
84 dB CH MIC INPUT → GROUP OUT/ST OUT (CH to ST)
94 dB CH MIC INPUT → ST OUT (GROUP to ST)
62.2 dB CH MIC INPUT → REC OUT (CH to ST)
76 dB CH MIC INPUT → AUX SEND (PRE)
86 dB CH MIC INPUT → AUX SEND (POST)/EFFECT SEND
58 dB CH LINE INPUT → GROUP OUT/ST OUT (CH to ST)
Maximum Voltage Gain
2
84 dB ST CH MIC INPUT → GROUP OUT/ST OUT (CH to ST)
58 dB ST CH LINE INPUT → GROUP OUT/ST OUT (ST to ST)
47 dB ST CH LINE INPUT → AUX SEND (PRE)
57 dB ST CH LINE INPUT → AUX SEND (POST)/EFFECT SEND
34 dB ST CH INPUT → GROUP OUT/ST OUT (ST to ST)
16 dB AUX RETURN → ST OUT
9 dB AUX RETURN → AUX SEND
27.8 dB 2TR INPUT → ST OUT
Monaural/Stereo Input Gain Control 44 dB variable
Monaural/Stereo High Pass Filter 80 Hz 12 dB/octave
Crosstalk (1 kHz)
-70 dB between input channels
-70 dB between input/output channels (CH INPUT)
+/-15 dB
Monaural Input Channel Equalization: HIGH 10 kHz shelving
Max. Variation (CHs 1 to 8)
3
MID 0.25-5 kHz peaking
LOW 100 Hz shelving
+/-15 dB
Stereo Input Channel Equalization:
HIGH 10 kHz shelving
HI-MID 3 kHz peaking
Max. Variation (CHs 9/10 to 15/16)
3
LO-MID 800 Hz peaking
LOW 100 Hz shelving
Graphic Equalizer
7-band (125, 250, 500 1 k, 2 k, 4 k, 8 k)
Max. Variation +/-12 dB
Internal Digital Effects 16 programs, parameter control
Monaural/Stereo Input Peak Indicator
On each channel: red indicator lights if post-EQ signal (on ST channels, if either post-EQ sig-
nal or post-mic-amp signal) comes within 3 dB of the clipping level.
Two 12-point LED meters [Stereo (L, R)]
Level Meters
Peak point: red indicator
+5, +3, +1, and 0 points: yellow indicators
-1, -3, -5, -7, -10, -15, -20: green indicators
Phantom +48 VDC Power (Balanced input) Supplied when Phantom +48 V switch is ON.
Included Accessory Power adaptor (PA-30)
USA and Canada: 120 V AC, 60 Hz
Europe: 230 V AC, 50 Hz
Power Supply Australia: 240 V AC, 50 Hz
Korea: 220 V AC, 60 Hz
China: 220 V AC, 50 Hz
Power Consumption 51 W
Max. Dimensions (W x H x D) 423 x 108 x 416.6 mm
Weight 5.5 kg
