Yamaha MT-09 User Manual

Instrument and control functions
6-11
6
Clock
The clock uses a 12-hour time system.
The clock is updated automatically
from connected smartphones or can
also be manually set in “ Settings” →
“Clock”. (See page 6-30.)
Speedometer
The speedometer shows the vehicle’s
traveling speed.
Tachometer
The tachometer shows the engine
speed, as measured by the rotational
velocity of the crankshaft, in revolu-
tions per minute (r/min).
NOTICE
ECA10032
Do not operate the engine in the ta-
chometer red zone.
Red zone: 10500 r/min and above
Transmission gear display
This display shows which gear the
transmission is in. This vehicle has 6
gears and a neutral position. The neu-
tral position is indicated by the neutral
indicator light “ ” and by the trans-
mission gear display reading: “ ”.
YRC mode display
This display indicates which YRC
mode is currently selected: “SPORT”,
“STREET”, “RAIN”, “CUSTOM 1” and
“CUSTOM 2”.
Cycle through the YRC modes by us-
ing the YRC mode button “MODE” and
also view/customize them in the menu
system. (See page 6-27.)
TIP
The names of “CUSTOM 1” and “CUS-
TOM 2” can also be customized via the
Yamaha Motorcycle Connect app.
In Theme4:
In this theme, the YRC mode display is
expanded to show the current “PWR”,
“TCS”, “SCS”, and “LIF” settings for
each YRC mode. In addition to using
the YRC mode button “MODE”, you
can move the joystick up-down to cy-
cle between the vehicle information
display and the YRC mode display.
When highlighted, short press “ ” to
select the YRC mode display. Move
the joystick left-right to cycle between
the available items. Move the joystick
up-down to cycle the highlighted YRC
mode or change the setting for the
highlighted item.
In Theme1-3:
Long press the YRC mode button
“MODE” to open/close an expanded
YRC mode pop-up at the bottom of the
screen. While the pop-up is open,
short press the YRC mode button
“MODE” to cycle through the presets
and use the joystick to adjust individual
items.
TIP
If the selected YRC mode is customiz-
able, “PWR”, “TCS”, “SCS”, and “LIF”
can be highlighted and adjusted using
the joystick.
For more information on YRC modes
see page 4-1.
UBMEE0E0.book Page 11 Thursday, March 7, 2024 10:23 AM

Yamaha MT-09 Specifications

General

Displacement	889cc
Bore x Stroke	78.0 mm x 62.1 mm
Compression Ratio	11.5 : 1
Fuel System	Fuel Injection
Starter System	Electric
Transmission	6-speed
Final Drive	Chain
Frame	Diamond
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve, inline-3 cylinder
Front Brake	Dual 298mm hydraulic discs
Rear Brake	Hydraulic disc, 245mm
Front Tire	120/70ZR17M/C (58W)
Rear Tire	180/55ZR17M/C (73W)
Wheelbase	1, 430 mm (56.3 in)
Fuel Capacity	3.7 gal
Front Suspension	Inverted fork
