CS-R5 Owner’s Manual
30
General Specifications
Audio Specifications
At the time of measurement, all levels are set to nominal. Output impedance of the signal generator is 150Ω.
Frequency response
@20 Hz–20 kHz, reference to the nominal output level @1 kHz
Total harmonic distortion
* Total Harmonic Distortion is measured with an 18 dB/oct filter @80 kHz.
Hum & noise
*2
Specifications
Mixing capacity 288 Inputs, 72 MIX + 36 MATRIX + 2 STEREO (DSP-RX-EX)
Sampling
frequency
Internal clock Frequency 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Accuracy ±50 ppm
Jitter
*1
*1. Measured at the AES/EBU OUT.
1.0 ns @Fs=88.2 kHz/96 kHz, 2.0 ns @Fs=44.1 kHz/48 kHz
User interface 100 mm touch-sensitive motorized fader (resolution=1024 steps) × 38
15" multi-touch screen (high brightness, wide view angle) × 3
Touch sensitive knobs in the Selected Channel section
Power requirements 100-240 V, 50/60 Hz
Power consumption 300 W
Dimensions W × H × D 1444 mm × 414 mm × 643 mm (including the rubber feet)
Weight 42 kg
NC value
*2
*2. Measured 30 cm horizontally away and vertically up from the unit (front pad).
FAN speed LOW: NC=15 / HIGH: NC=25
Temperature
range
Operating temperature range Min: 0°C, Max: 40°C
Storage temperature range Min: –20°C, Max: 60°C
Accessories Owner’s Manual, AC power cord × 2, Dust cover, Nuendo Live (DAW software)
Optional items Mini-YGDAI card, Gooseneck Lamp LA1L
Input Output RL Conditions Min. Typ. Max. Unit
OMNI IN 1–8 OMNI OUT 1–8 600Ω GAIN: +66 dB –1.5 0.0 0.5 dB
Input Output RL Conditions Min. Typ. Max. Unit
OMNI IN 1–8 OMNI OUT 1–8 600Ω +4 dBu@20 Hz–20 kHz, GAIN: –6 dB 0.05 %
Internal OSC OMNI OUT 1–8 600Ω Full scale output @1 kHz 0.02 %
Internal OSC PHONES 8Ω
Full scale output @1 kHz,
PHONES A/B LEVEL: max.
0.2 %
Input Output RL Conditions Min. Typ. Max. Unit
OMNI IN 1–8 OMNI OUT 1–8 600Ω Rs= 150Ω, GAIN: +66 dB
–128
EIN
*1
*1. EIN=Equivalent Input Noise
*2. Hum & noise is measured with an IHF-A filter.
dBu
–62 dBu
OMNI IN 1–8 OMNI OUT 1–8 600Ω Rs= 150Ω, GAIN: –6 dB –91 –86 dBu
— OMNI OUT 1–8 600Ω
Residual output noise,
output channel is off.
–96 dBu
— PHONES 8Ω
Residual output noise,
PHONES A/B LEVEL: min.
–88 dBu
