Yamaha RIVAGE PM5 User Manual

CS-R5 Owner’s Manual
31
Dynamic range
* Dynamic range is measured with an IHF-A filter.
Crosstalk (@1kHz)
* Crosstalk is measured with a 30 dB/oct filter @22 kHz.
Input/output Characteristics
Analog input characteristics
*3*4
Analog output characteristics
*5
Digital I/O characteristics
Input Output RL Conditions Min. Typ. Max. Unit
OMNI IN 1–8 OMNI OUT 1–8 600Ω AD + DA, GAIN: –6 dB 115 dB
— OMNI OUT 1–8 600Ω DA Converter 120 dB
from/to to/from Conditions Min. Typ. Max. Unit
OMNI IN n OMNI IN (n-1) or (n+1)
OMNI IN 1–8,
adjacent inputs, GAIN: –6 dB
–100 dB
OMNI OUT n OMNI OUT (n-1) or (n+1) OMNI OUT 1–8, input to output –100 dB
Input Jack Gain
Input
Impedance
Source
Impedance
Input Level
Connector
Sensitivity
*1
*1. Sensitivity is defined as the input level required to produce an output of +4 dBu (1.23 V) or the nominal output level when all faders
and level controls are set to maximum.
Rated Level
Max. Level
Before
Clipping
OMNI IN
1–8
+66 dB
7.5 kΩ
50–600Ω Mics &
600Ω Lines
–82 dBu
(61.6 μV)
–62 dBu
(0.616 mV)
–42 dBu
(6.16 mV)
XLR-3-31 type (Balanced)
*2
*2. 1= GND, 2= HOT, 3= COLD
*3. 0 dBu= 0.775 Vrms
*4. OMNI IN 1-8 feature +48V DC phantom power, which is switchable for each jack individually.
–6 dB
–10 dBu
(245 mV)
+10 dBu
(2.45 V)
+30 dBu
(24.5 V)
Output Jack
Output
Impedance
Load
Impedance
Max Output
Level Select
Switch
*1
*1. The unit features an internal switch to change the maximum output level.
Output Level
Connector
Rated Level
Max. Level Before
Clipping
OMNI OUT
1–8
75Ω 600Ω Lines
+24 dBu
(default)
+4 dBu
(1.23 V)
+24 dBu
(12.3 V)
XLR-3-32 type (Balanced)
*2
*2. 1=GND, 2=HOT, 3=COLD
+18 dBu
–2 dBu
(0.616 V)
+18 dBu
(6.16 V)
PHONES
A, B
15Ω
8Ω Phones – 75 mW
*3
*3. These measurements were obtained when the PHONES A/B LEVEL knobs were set 10 dB lower than the maximum.
150 mW
Stereo Phone Jack (TRS)
(Unbalanced)
*4
*4. Tip=LEFT, Ring=RIGHT, Sleeve=GND
*5. 0 dBu= 0.775 Vrms
40Ω Phones – 65 mW
*3
150 mW
Jack Format Data Length Level Audio Connector
AES/EBU IN 1/2, 3/4
*1
*1. Features sampling rate converters.
Supported input/output frequency: 40-102 kHz
AES/EBU 24 bit RS422 2ch input XLR-3-31 type (Balanced)
*2
*2. 1=GND, 2=HOT, 3=COLD
AES/EBU OUT 1/2, 3/4
*1
AES/EBU 24 bit RS422 2ch output XLR-3-32 type (Balanced)
*2
