30
RX-V681/RX-A760
RX-V681/RX-A760
■ SELF-DIAGNOSTIC FUNCTION
This unit has self-diagnostic functions that are intended for inspection, measurement and location of faulty point.
Each item has a main menu, each of which has sub-menu items.
Listed in the table below are main menu items and sub-menu items.
Note:
Some of the menu items listed below may not apply to the models covered in this service manual.
No. Main menu No. Sub-menu
A:
Audio system
A1 DSP AUDIO 1 DSP THROUGH
2 INVALID ITEM
(Not for service)
A2 DIRECT AUDIO 1 ANALOG DIRECT VH
2 ANALOG DIRECT VL
3 ANALOG DIRECT CENTER
4 ANALOG DIRECT SURROUND
5 ANALOG DIRECT SURROUND BACK
6 ANALOG DIRECT SUBWOOFER
7 INVALID ITEM
(Not for service)
A3 HDMI AUDIO 1 HDMI AUTO
2 INVALID ITEM
(Not for service)
3 ARC1
4 INVALID ITEM
(Not for service)
5 INVALID ITEM
(Not for service)
A4 AUDIO ROUTE CHECK 1 BI-AMP
2 Z-DSP THROUGH
3 D-PARTY MODE
4 FULL MUTE
5 INVALID ITEM
(Not for service)
6 INVALID ITEM
(Not for service)
7 INVALID ITEM
(Not for service)
8 INVALID ITEM
(Not for service)
9 HP MUTE
10 INVALID ITEM
(Not for service)
11 INVALID ITEM
(Not for service)
12 INVALID ITEM
(Not for service)
13 DISTRO DIGITAL
14 DISTRO DAAD
A5 CONTROL OUT TEST
(Not for service)
1 CONTROL OUT 1
2 CONTROL OUT 2
A6 MIC CHECK 1 MIC ROUTE CHECK
A7 MANUAL TEST 1 T
EST ALL
2 TEST FRONT L
3 TEST CENTER
4 TEST FRONT R
5 TEST SURROUND R
6 TEST SURROUND BACK R
7 TEST SURROUND BACK L
8 TEST SURROUND L
9 TEST FRONT PRESENCE L
10 TEST FRONT PRESENCE R
11 INVALID ITEM
(Not for service)
12 INVALID ITEM
(Not for service)
13 TEST LFE 1
14 INVALID ITEM
(Not for service)
D:
Display system
D1 FL CHECK 1 FL CHECK
2 ALL SEGMENT OFF
3 ALL SEGMENT ON
4 CHECK PATTERN 1
5 CHECK PATTERN 2
To Next Page
