36
Adjusting the Items on the SET
MENU
Adjustment should be made with the remote control.
Note
• Some items require extra steps to change to the desired setting.
1 Set the selector dial to the
AMP/TUN (or DSP/TUN)
position.
2 Press SET MENU to enter the SET MENU.
3 Press u/d repeatedly to select the item (1 to
15) you want to adjust.
y
• By pressing SET MENU repeatedly, you can select items in the
same order as when pressing d.
4 Press j or i once to enter the setup mode of
the selected item.
The last setting you adjusted appears on the video
monitor or on the front panel display.
SET MENU
ADVANCED OPERATION
3,6
4,5
1
2
The SET MENU consists of 15 items including the
speaker mode setting, center graphic equalizer and
parameter initialization features. Choose the appropriate
item and adjust or select the values as necessary.
y
• You can adjust the items on the SET MENU while playing a
source.
• We recommend that you adjust the items on the SET MENU
while using a video monitor. It is easier to see the video
monitor than it is to see the front panel display on this unit
while adjusting the items.
Note
• The indication on the front panel display is the abbreviation of
the OSD.
1 SPEAKER SET
1A CENTER SP
1B MAIN SP
1C REAR L/R SP
1D LFE/BASS OUT
1E MAIN LEVEL
2 LOW FRQ TEST
3 L/R BALANCE
4 HP TONE CTRL
5 CENTER GEQ
6 INPUT RENAME
7 I/O ASSIGNMENT
8 INPUT MODE
9 PARAM. INI
10 DOLBY D. SET
10A LFE LEVEL
10B D-RANGE
11 DTS LFE LEVEL
12 6.1/ES AUTO
13 SP DELAY TIME
14 DISPLAY SET
15 MEMORY GUARD
SET MENU 1/4
1 SPEAKER SET
2 LOW FRQ TEST
3 L/R BALANCE
4 HP TONE CTRL
:Up/Down
/
–/+ Enter
SET MENU 1/4
1 SPEAKER SET
2 LOW FRQ TEST
3 L/R BALANCE
4 HP TONE CTRL
:Up/Down
/
–/+ Enter
2 LOW FRQ TEST
TEST TONE • • • • • OFF
OUTPUT • • • MAIN L/R
FRQ • • • • • • • • • • 88Hz
